SYSTEM FOR SUMMING UP TO 8 INTERNET CHANNELS USING MPTCP TECHNOLOGY
What it is?
The main difference between LiveLTE and alternative and often more budget solutions is the ability to work in single connection mode
This key feature makes it possible to widely use LiveLTE for organizing a main or backup Internet connection, if necessary, to organize an online broadcast from a location where there is no fixed connection or it is unstable.
The main method of transferring information to LiveLTE is LTE modems connected to different cellular operators. However, if desired, an Ethernet cable connection can also act as one of the communication channels.
THE LIVELTE SYSTEM IS BASED ON A DISTRIBUTED CONNECTION OF TWO POINTS
Scheme of work
Point A: a router at the site where you need to organize an Internet connection. Mini-PCs with modified openWRT firmware are used as such a router. This is where traffic is split.
Point B: Cloud VPS Summarization Server. It sums up packets from point A through several channels.
Thus, any connection from point A will come from the IP address of point B.
LiveLTE on AVStream
Detailed review and analysis of equipment and operating principles
COMPACT
01
The entire set fits in a small transport case (included)
REMOVABLE UNIT WITH MODEMS
02
To improve the quality of communication, the unit with modems can be removed from the case cover and fixed, for example, on a window glass
MONITORING SYSTEM
03
You can monitor the status of the system through the web interface, which displays the current indicators of the overall speed, as well as the speed for each connection
CONTENTS OF DELIVERY
ATTENTION! So far, SIM cards are NOT included in the package! This option will be added soon
Pre-configured mini-pc (sharing router)
Active USB hub
Pre-configured USB LTE modems
Ethernet cable 30 meters
Pre-configured summarizing VPS server
Mounting kit for modem box
User's manual
Technical support 24/7 in Telegram
Carrying case
QUESTIONS AND ANSWERS
- Install SIM cards in modems
- Enable the VPS server using the granted access to the Personal Account.
- Enable sharing router
- Connect the sharing router to your PC or your router.
- Wait 1-2 minutes for the sharing router to load and the modems to initialize
- Use the summarized internet
- At the end of use, turn off the separating router and summarizing VPS according to the access provided in the Personal Account.
The presented solution is not an encoder, but serves to organize a full-fledged Internet connection via Ethernet (RJ-45). In addition, it is possible to aggregate up to 8 LTE channels.
Each build undergoes a load test of 48 hours of stream.
In real conditions, "combat" broadcast - the maximum time was recorded at around 15 hours of continuous stream.
In real conditions, "combat" broadcast - the maximum time was recorded at around 15 hours of continuous stream.
An active VPS costs 2 rubles per hour.
During downtime, the cost is 100 rubles per month and includes the rental of a permanent IP address.
During downtime, the cost is 100 rubles per month and includes the rental of a permanent IP address.
At the moment, LiveLTE summarizing VPS servers are deployed in the following cities:
- Moscow
- St. Petersburg
- Novosibirsk
Any connections via TCP and UDP protocols are supported, including: RTMP, SRT, vMix Call, Skype, Zoom
The total connection speed depends on:
- Modem unit installation locations
- Technical characteristics and settings of base stations of cellular operators
- Day of the week and time of day (total load on the BS)
No, the total speed will be lower than the arithmetic sum of all modem speeds separately, since the MPTCP protocol transmits backup packets of each connection through the others. This allows you to recover lost packets in case of disconnection (loss of connection) of any of the channels. In this case, the connection will not be broken, and the load is automatically distributed to the remaining communication channels.
Yes it is possible. To do this, connect a USB-Ethernet adapter to a free USB port.
Yes, you can ask them on the AVStream Telegram community https://t.me/avstreamchat
Yes, for invoicing, please write to Telegram with the details and the selected configuration or leave a comment when placing an order.
The invoice will be issued WITHOUT VAT.
The invoice will be issued WITHOUT VAT.
All kits are guaranteed 1 year technical support from the date of purchase. In fact, this period will be extended until the moment the 5G mobile networks enter the wide market.
If you are in the cities of presence of LiveLTE kits, then there is an opportunity to rent a kit WITH SERVICE. If desired, the same kit can be purchased locally.
INTERNET ALREADY
RESERVED*
RESERVED*
* - for the events with online streams
